Omron GX-ID1611 User Manual

7 Digital I/O Slave Unit
7 - 14
GX-series EtherCAT Slave Unit User’s Manual
Notes For the I/O power supply current value to V and G terminals, refer to "A-5 I/O Power Supply Current" in
Page A - 79.
7-4-2 2-tier Terminal Block Type 16-point Output Slave Unit
GX-OD1611/OD1621
Specification
Item
Specification
GX-OD1611 GX-OD1621
Output capacity 16 points
Rated current
(ON current)
0.5 A/output, 4.0 A/common
Internal I/O common NPN PNP
Residual voltage
1.2 V max.
(0.5 ADC, between each output terminal
and the G terminal)
1.2 V max.
(0.5 ADC, between each output terminal
and the V terminal)
Leakage current 0.1 mA max.
ON delay 0.5 ms max.
OFF delay 1.5 ms max.
Number of circuits per
common
16 points/common
Output indicators LED display (yellow)
Isolation method Photocoupler isolation
I/O power supply method Supply by I/O power supply
Unit power supply current
consumption
90 mA max. (for 20.4 to 26.4-VDC power supply voltage)
I/O power supply current
consumption
10 mA max. (for 20.4 to 26.4-VDC power supply voltage)
Weight 180 g max.
Expansion functions Enabled
Error Mode Output Select either hold or clear.
Short-circuit protection
function
No
