Connect the dedicated e-CON connector to the cables of the external device to be connected and then
connect it to the connector terminal.
The wire size and sheath diameter of applicable cables vary by the type of e-CON connector.
Use the next table to check that the e-CON connectors to be used conform to the wire size and sheath
diameter of the cables of the connected device.
Tyco Electronics connectors
Sumitomo 3M connectors
Panasonic Electric Works connectors
OMRON connectors
4-4-2 Connecting to e-CON Connector Terminals
Checking the e-CON connector and cable wire size
Model Housing color Applicable wire range
3-1473562-4 Orange Sheath diameter: 0.6 to 0.9 mm
Cross-sectional area: 0.08 to
0.5 mm
2
1-1473562-4 Red Sheath diameter: 0.9 to 1.0 mm
1473562-4 Yellow Sheath diameter: 1.0 to 1.15 mm
2-1473562-4 Blue Sheath diameter: 1.15 to 1.35 mm
4-1473562-4 Green Sheath diameter: 1.35 to 1.60 mm
Model Housing color Applicable wire range
37104-3101-000FL Red
AWG26 (0.14mm
2
) to AWG24 (0.2mm
2
)
Sheath diameter: 0.8 to 1.0 mm
37104-3122-000FL Yellow
AWG26 (0.14mm
2
) to AWG24 (0.2mm
2
)
Sheath diameter: 1.0 to 1.2 mm
37104-3163-000FL Orange
AWG26 (0.14mm
2
) to AWG24 (0.2mm
2
)
Sheath diameter: 1.2 to 1.6 mm
37104-2124-000FL Green
AWG22 (0.3mm
2
) to AWG20 (0.5mm
2
)
Sheath diameter: 1.0 to 1.2 mm
37104-2165-000FL Blue
AWG22 (0.3mm
2
) to AWG20 (0.5mm
2
)
Sheath diameter: 1.2 to 1.6 mm
37104-2206-000FL Gray
AWG22 (0.3mm
2
) to AWG20 (0.5mm
2
)
Sheath diameter: 1.6 to 2.0 mm
Model Housing color Applicable wire range
AXF12142 Red
AWG22 (0.3mm
2
) to AWG20 (0.5mm
2
)
Sheath diameter: 1.2 to 2.0 mm
AXF12146 Yellow
AWG28 (0.08mm
2
) to AWG24 (0.2mm
2
)
Sheath diameter: 0.7 to 1.2 mm
Model Specification Applicable wire range
XN2A-1470
Spring
clamp type
AWG28 (0.08mm
2
) to AWG20 (0.5mm
2
)
Sheath diameter: 1.5 mm max.
