6 - 3
6 Basic Specifications of Slave Units
GX-series EtherCAT Slave Unit User’s Manual
6-2 General Specifications
6
6-2 General Specifications
This section provides the general specifications of GX-series Digital I/O Slave Units, Analog I/O Slave
Units, and Encoder Input Slave Units.
Refer to "10-4-1 Specifications" in page 10 - 9 for the general specifications for the GX-ILM08C.
* Applicable only to 2-tier terminal block and 3-tier terminal block type Slave Units.
Item Specification
Unit power supply voltage 20.4 to 26.4 VDC (24 VDC −15% to +10%)
I/O power supply voltage 20.4 to 26.4 VDC (24 VDC −15% to +10%)
Noise immunity Conforms to IEC 61000-4-4, 2 kV (power line).
Vibration resistance
Malfunction 10 to 60 Hz with amplitude of 0.7 mm, 60 to 150Hz and 50 m/s
2
in each
of X, Y, and Z directions for 80 minutes
<GX-OC1601 Relay Output Unit only>
10 to 55 Hz with double-amplitude of 0.7 mm in each of X, Y, and Z directions for 80
minutes
Shock resistance
150 m/s
2
with amplitude of 0.7 mm
<GX-OC1601 Relay Output Unit only>
100 m/s
2
(3 times each in 6 directions on 3 axes)
Dielectric strength 600 VAC (between isolated circuits)
Insulation resistance 20 MΩ or more (between isolated circuits)
Ambient operating
temperature
−10 to 55 °C
Ambient operating
humidity
25% to 85% (with no condensation)
Ambient operating
atmosphere
No corrosive gases
Storage temperature −25 to 65 °C
Storage humidity 25% to 85% (with no condensation)
Terminal block screws
tightening torque*
M3 wiring screws: 0.5 N • m
M3 terminal block mounting screws: 0.5 N • m
Mounting method 35-mm DIN track mounting
