A - 29
A
Appendix
GX-series EtherCA
T Slave Unit User
’
s Manual
A-1 Object Dictionary
A
A-1-6 Sync Manager Communication Object
•
IO-Link Ma
ster Unit
Model
Sync manager 2 PD
O
assignment
Sync manager 3 PDO
assignment
Number of
assigned
RxPDOs
Assigned
PDO 1
Number
of
assigned
TxPDOs
Assigned
PDO 1
GX-ILM08C
09 hex
1600 hex
1601 hex
1602 hex
1603 hex
1604 hex
1605 hex
1606 hex
1607 hex
1700 hex
10 hex
1A00 hex
1A01 hex
1A02 hex
1A03 hex
1A04 hex
1A05 hex
1A06 hex
1A07 hex
1B00 hex
1B01 hex
1B02 hex
1B03 hex
1B04 hex
1B05 hex
1BFE hex
1BFF hex
332
334
