10 - 17
10 IO-Link Master Unit
GX-series EtherCA
T Slave Unit User
’
s Manual
10-5 Mounti
ng Dimensio
ns
10
10-5
Mounting Dimensions
The mountin
g dimen
sions of the
IO-Link M
aster Unit
are shown
below
.
GX-ILM08C
(mm)
13.5
46.5
15.1
44.9
22
18.3
57.5
86
111
136
161
60
175
40.7
49.1
24.8
32.8
35.15
Two, M5
or 5.3-dia. holes
Mounting dimensions
165±0.2
252
254
