Trial Operation
4-5
Basic Settings
Before starting the Inverter ensure that it is initialized, i.e. all parameters are set to their factory defaults.
Therefor set parameter A1-03 to 2220 for 2-wire initialization or to 3330 for 3-wire initialization. Refer to
page 6-9, Run Command for details about 2-wire and 3-wire initialization.
Refer to Chapter 3, Digital Operator and Modes for Digital Operator operating procedures. Find a list of the
Quick Programming Parameters on page 5-4, User Parameters Available in Quick Programming Mode and
details of the parameters in Chapter 6, Parameter Settings by Function.
Table 4.1 Basic Parameter Settings
: Must be set. : Set as required.
Class
Parameter
Number
Name Description
Setting
Range
Factory
Setting
Page
b1-01
Reference selec-
tion
Sets the frequency reference input
method.
0: Digital Operator
1: Control circuit terminal
(analog input)
2: MEMOBUS communications
3: Option Card
0 to 3 1
6-5
6-52
b1-02
Operation method
selection
Sets the run command input method.
0: Digital Operator
1: Control circuit terminal (digital input)
2: MEMOBUS communications
3: Option Card
0 to 3 1
6-9
6-52
b1-03
Stopping method
selection
Selects stopping method when stop com-
mand is sent.
0: Deceleration to stop
1: Coast to stop
2: DC braking stop
3: Coast to stop with timer
0 to 3 0 6-11
C1-01
Acceleration
time 1
Sets the acceleration time in seconds for
the output frequency to climb from 0% to
100%.
0.0 to 6000.0 10.0 s
4-11
6-15
C1-02
Deceleration
time 1
Sets the deceleration time in seconds for
the output frequency to fall from 100% to
0%.
0.0 to 6000.0 10.0 s
4-11
6-15
d1-01 to
d1-04 and
d1-17
Frequency refer-
ences 1 to 4 and
jog frequency ref-
erence
Sets the required speed references for
multi-step speed operation or jogging.
0 to 200.00 Hz
d1-01 to
d1-04: 0.00
Hz
d1-17: 6.00
Hz
6-7
E1-01
Input voltage set-
ting
Sets the Inverter's nominal input voltage
in volts.
155 to
255 V
*1
200 V
*1
6-19
6-100
E2-01
Motor rated cur-
rent
Sets the motor rated current.
0.32 to 6.40
*2
1.90 A
*3
6-33
6-99
L1-01
Motor protection
selection
Used to enable or disable the motor over-
load protection function.
0: Disabled
1: Protection for general purpose motor
(fan cooled)
2: Protection for inverter motor (exter-
nally cooled motor)
3: Vector motor protection
0 to 3 1 6-33
To Next Page
