 Setting Values that Change with the V/f Pattern Selection (E1-03)
200 V and 400 V Class Inverters of 0.4 to 1.5 kW
200 V and 400 V Class Inverters of 2.2 to 45 kW
200 V Class Inverters of 55 to 110 kW and 400 V Class Inverters of 55 to 300 kW
Parameter
Number
Unit Factory Setting
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E F FF
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0
E1-05
*1
*1. These are values for a 200 V class Inverter. Values for a 400 V class Inverter are double
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0
E1-06 Hz50.060.050.060.050.050.060.060.050.050.060.060.060.060.060.050.050.0
E1-07
*1
Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 2.5 2.5
E1-08
*1
V 15.015.015.015.035.050.035.050.019.024.019.024.015.015.015.015.012.0
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.2 1.2
E1-10
*1
V 9.0 9.0 9.0 9.0 8.0 9.0 8.0 9.0 11.0 13.0 11.0 15.0 9.0 9.0 9.0 9.0 6.0
Parameter
Number
Unit Factory Setting
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E F FF
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0
E1-05
*1
*1. These are values for a 200 V class Inverter. Values for a 400 V class Inverter are double
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 50.0 50.0
E1-07
*1
Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 2.5 2.5
E1-08
*1
V 14.0 14.0 14.0 14.0 35.0 50.0 35.0 50.0 18.0 23.0 18.0 23.0 14.0 14.0 14.0 14.0 15.0
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.2 1.2
E1-10
*1
V 7.0 7.0 7.0 7.0 6.0 7.0 6.0 7.0 9.0 11.0 9.0 13.0 7.0 7.0 7.0 7.0 9.0
Parameter
Number
Unit Factory Setting
E1-03 - 0 1 2 3 4 5 6 7 8 9 A B C D E F FF
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0
E1-05
*1
*1. These are values for a 200 V class Inverter. Values for a 400 V class Inverter are double
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0
E1-06 Hz50.060.050.060.050.050.060.060.050.050.060.060.060.060.060.050.050.0
E1-07
*1
Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 2.5 2.5
E1-08
*1
V 12.012.012.012.035.050.035.050.015.020.015.020.012.012.012.012.014.0
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.2 1.2
E1-10
*1
V 6.0 6.0 6.0 6.0 5.0 6.0 5.0 6.0 7.0 9.0 7.0 11.0 6.0 6.0 6.0 6.0 7.0
