XII
Line Filters
The IP54 version is already equipped with a internal EMC filter. For the IP00 and NEMA 1 / IP20 versions of
the Varispeed E7 the recommended line filters are as follows:
îš„Recommended Line Filters for Varispeed E7 (IP00 and NEMA 1 / IP20)
Permissible emission of power drive systems for commercial and light environment (EN61800-3, A11)
(general availability, 1st environment)
Inverter Model Line Filter
Varispeed E7
(IP00/20)
Model
EN
55011 Class
Current
(A)
Weight
(kg)
Dimensions
W x D x H
CIMR-E7Z40P4
3G3RV-PFI3010-SE
B, 25 m
*1
*1. Class A, 100 m
10 1.1 141 x 46 x 330
CIMR-E7Z40P7
CIMR-E7Z41P5
CIMR-E7Z42P2
CIMR-E7Z43P7
3G3RV-PFI3018-SE 18 1.3 141 x 46 x 330CIMR-E7Z44P0
CIMR-E7Z45P5
CIMR-E7Z47P5
3G3RV-PFI3035-SE 35 2.1 206 x 50 x 355
CIMR-E7Z4011
CIMR-E7Z4015
3G3RV-PFI3060-SE 60 4.0 236 x 65 x 408
CIMR-E7Z4018
CIMR-E7Z4022
3G3RV-PFI3070-SE
A, 100 m
70 3.4 80 x 185 x 329
CIMR-E7Z4030
CIMR-E7Z4037
3G3RV-PFI3130-SE 130 4.7 90 x 180 x 366CIMR-E7Z4045
CIMR-E7Z4055
CIMR-E7Z4075 3G3RV-PFI3170-SE 170 6.0 120 x 170 x 451
CIMR-E7Z4090
3G3RV-PFI3200-SE 250 11 130 x 240 x 610
CIMR-E7Z4110
CIMR-E7Z4132
3G3RV-PFI3400-SE 400 18.5 300 x 160 x 610
CIMR-E7Z4160
CIMR-E7Z4185
3G3RV-PFI3600-SE 600 11,0 260 x 135 x 386
CIMR-E7Z4220
CIMR-E7Z4300 3G3RV-PFI3800-SE 800 31.0 300 x 160 x 716
