Frequency Reference
6-7
îš‹ Using Multi-Step Speed Operation
With Varispeed E7 series Inverters the speed can be changed in a maximum of 5 steps, using 4 multi-step fre-
quency references and one jog frequency reference.
The following example of a multi-function input terminal function shows a 5-step operation using multi-step
references 1 and 2 and jog frequency selection functions.
îš„Related Parameters
To switch frequency references, set multi-step references 1 and 2 and the jog reference selection in the multi-
function digital inputs.
Multi-function Digital Inputs (H1-01 to H1-04)
Combining Multi-Step Speed References and Multi-Function Digital Inputs
The frequency reference can be changed by combining the ON/OFF status of S4 to S6 (multi-function digital
input terminals). The following table shows the possible combinations.
Setting Precautions
When setting analog inputs to step 1 and step 2, observe the following precautions.
• When setting terminal A1's analog input to step 1 set b1-01 to 1, when setting d1-01 (Frequency Reference
1) to step 1 set b1-01 to 0.
• When setting terminal A2's analog input to step 2 set H3-09 to 2 (auxiliary frequency reference). When
setting d1-02 (Frequency Reference 2) to step 2 set H3-09 to 1F (do not use analog inputs).
Terminal
Parameter
Number
Set Value Details
S5 H1-03 3
Multi-step speed command 1 (Also used for master speed/auxiliary speed
switching when multi-function analog input H3-09 is set to 2 (auxiliary
frequency reference).)
S6 H1-04 4 Multi-step speed command 2
S7 H1-05 6 Jog frequency selection (given priority over multi-step speed command)
Speed
Terminal S5 Terminal S6 Terminal S7
Selected Frequency
Multi-step Speed
Command 1
Multi-step Speed
Command 2
Jog Frequency
Selection
1 OFF OFF OFF Frequency reference 1, d1-01, master speed frequency
2 ON OFF OFF Frequency reference 2, d1-02, auxiliary frequency
3 OFF ON OFF Frequency reference 3, d1-03
4 ON ON OFF Frequency reference 4, d1-04
5– –
ON
*1
*1. Terminal S6's jog frequency selection is given priority over multi-step speed commands.
Jog frequency d1-17
To Next Page
