Modes
3-5
Modes
This section describes the Inverter's modes and switching between modes.
îš‹ Inverter Modes
The Inverter's user parameters and monitoring functions are organized in groups called modes that make it
easier to read and set user parameters. The Inverter is equipped with 5 modes.
The 5 modes and their primary functions are shown in the Table 3.2.
Table 3.2 Modes
Mode Primary function(s)
Drive mode
The Inverter can be run in this mode.
Use this mode for monitoring values such as frequency references or output current,
displaying fault information and the fault history.
Quick programming mode Use this mode to read and set the basic user parameters to operate the Inverter.
Advanced programming mode Use this mode to reference and set all user parameters.
Verify mode
Use this mode to read/set user parameters that have been changed from their fac-
tory-set values.
Autotuning mode
Use this mode when running a motor with unknown motor parameters. During
Autotuning the line-to-line resistance is measured and set automatically.
