7-16
îš‹ If the Motor Does Not Operate
îš„The motor does not operate when the RUN key on the Digital Operator is pressed.
The following causes are possible.
The operation method setting is wrong.
If parameter b1-02 (RUN command source selection) is set to 1 (control circuit terminal), the motor will not
operate when the RUN key is pressed. Either press the LOCAL/REMOTE key to switch to Digital Operator
operation or set b1-02 to 0 (Digital Operator).
The frequency reference is too low.
If the frequency reference is set below the frequency set in E1-09 (Minimum Output Frequency), the Inverter
will not operate.
Raise the frequency reference to at least the minimum output frequency.
îš„The motor does not operate when an external operation signal is input.
The following causes are possible.
The Inverter is not in Drive Mode.
If the Inverter is not in drive mode, it will remain in ready status and will not start. Press the MENU key make
the DRIVE LED flash, and enter the drive mode by pressing the DATA/ENTER key. The DRIVE LED will
light up when Drive Mode is entered.
The RUN command source selection is wrong.
If parameter b1-02 (reference selection) is set to 0 (Digital Operator), the motor will not operate when an
external operation signal is input. Set b1-02 to 1 (control circuit terminal) and try again.
The motor will also not operate if the LOCAL/REMOTE key has been pressed to switch to Digital Operator
operation. In that case press the LOCAL/REMOTE key again to return to the original setting.
3-wire control is enabled.
The input method for a 3-wire control is different than when operating by forward/stop and reverse/stop (2-
wire control). If a 3 wire control is selected, the motor will not operate when a wiring that is suitable for 2-wire
control is used. When using a 3-wire control, refer to the wiring example and timing chart on page 6-10, Per-
forming Operations Using 3-Wire Control and input the proper signals.
When using a 2-wire control, set the multi-function digital input (H1-01 through H1-05, terminals S3 to S7) to
a value other than 0.
NOTE
The LOCAL/REMOTE key can be enabled or disabled by setting o2-01. It is enabled when the Drive
Mode is entered and o2-01 is set to 1.
NOTE
The LOCAL/REMOTE key can be enabled or disabled by setting o2-01. It is enabled when the
drive mode is entered and o2-01 is set to 1.
