6-52
Input Terminal Functions
îš‹ Temporarily Switching Operation between Digital Operator
and Control Circuit Terminals
The Inverter’s run command and frequency reference inputs can be switched between local (i.e., Digital Oper-
ator) and remote (input method set in b1-01 and b1-02).
If any parameter from H1-01 to H1-05 (terminal S3 to S7 function selection) has been set to 1 (local/remote
selection), this input can be used to switch over between local and remote operation.
To set the frequency reference source and RUN command source to control circuit terminals, set b1-01 and
b1-02 to 1.
îš„Related Parameters
Multi-function Digital Inputs (H1-01 to H1-05)
Parameter
Number
Name
Setting
Range
Factory
Setting
Change
during
Operation
Access
Level
b1-01 Reference selection 0 to 3 1 No Q
b1-02 RUN command source selection 0 to 3 1 No Q
Set Value Function
1 Local/Remote selection (ON: Operator; OFF: Parameter b1-01/b1-02 setting)
NOTE
Local/remote switching can also be performed using the LOCAL/REMOTE key on the Digital Opera-
tor. When the local/remote selection has been set for one external terminal, the LOCAL/REMOTE key
function on the Digital Operator will be disabled.
