Inverter Protection
6-47
Inverter Protection
îš‹ Inverter Overheat Protection
The Inverter is protected against overheating using a thermistor that detects the heatsink temperature.
Related Parameters
Multi-function Digital Outputs (H2-01 to H2-02)
When the overheat temperature level is reached the inverter output is switched off.
To prevent a sudden and unexpected stop of the inverter due to an overtemperature, an overheating pre-alarm
can be output. Parameter L8-02 selects the pre-alarm temperature level, parameter L8-03 selects the inverter
reaction on the pre-alarm:
• Setting 0: The Inverter decelerates to stop using deceleration time C1-02, OH fault is output.
• Setting 1: The Inverter coasts to stop, OH fault is output.
• Setting 2: The Inverter decelerates to stop using the emergency stop time C1-09, OH fault is output.
• Setting 3: The Inverter will continue operation and only display an OH alarm on the operator display.
• Setting 4: The Inverter will continue operation but reduce the output frequency order to reduce the load.
Parameter L8-19 defines the decrease in output frequency as a percentage of the maximum output fre-
quency E1-04. An OH alarm is output.
Parameter
Number
Name
Setting
Range
Factory
Setting
Change
during
Operation
Access
Level
L8-02 Overheat pre-alarm level 50 to 130 95°CNo A
L8-03 Inverter overheat (OH) pre-alarm operation selection 0 to 4 4 No A
L8-19 Frequency reference during OH pre-alarm
0.0 to
20.0%
20.0% No A
Set Value Function
20 Inverter overheat pre-alarm (ON when overheat pre-alarm is active)
