10-6
User Parameters
A complete parameter table with the factory default settings can be found in the following table. The factory
settings are given for 200V class Inverter with 0.4 kW.
No. Name
Factory
Setting
Setting
A1-00
Language selection for digital operator display
(LED/HOA Digital Operator)
0
A1-01 Parameter access level 2
A1-03 Initialize 0
A1-04 Password 0
A1-05 Password setting 0
A2-01 to
A2-32
User-set parameters –
b1-01 Reference source selection 1
b1-02 RUN command source selection 1
b1-03 Stopping method selection 0
b1-04 Prohibition of reverse operation 0
b1-07 Operation selection after switching to remote mode 0
b1-08 Run command selection in programming modes 0
b1-11 RUN delay 0 sec.
b1-12 HAND frequency reference source selection 0
b1-13 HAND/AUTO switching during run selection 0
b1-14 Emergency override speed 0.00 Hz
b1-15 Emergency override reference selection 0
b2-01 DC injection braking starting frequency (Zero speed level) 0.5 Hz
b2-02 DC injection braking current 50%
b2-03 DC injection braking time at start 0.00 sec.
b2-04 DC injection braking time at stop 0.50 sec.
b2-09 Motor preheat current 0%
b2-10 Motor preheat current 2 5%
b3-01 Speed search selection 2
b3-02 Speed search operating current
120%
b3-03 Speed search deceleration time 2.0 sec.
b3-05 Speed search wait time 0.2 sec.
b3-14 Bi-directional speed search selection 1
b4-01 Timer function ON-delay time 0.0 sec.
b4-02 Timer function OFF-delay time 0.0 sec.
b5-01 PI control mode selection 0
b5-02 Proportional (P) gain 1.00
b5-03 Integral (I) time 1.0 sec.
b5-04 Integral (I) limit 100.0%
b5-06 PI limit 100.0%
b5-07 PI offset 0.0%
b5-08 PI delay time constant 0.00 sec.
b5-09 PI output characteristics selection 0
