Reference
Number
Feature Feature Description
5 Transfer key Transfers an active call to a contact.
6 Dial pad Enables you to enter numbers, letters, and special characters. You can also
use the dial pad keys to select menu items that have index numbers.
7 Messages key Enables you to access and manage instant and voice messages.
8 Hold key Holds an active call or resumes a held call.
9 Microphone Transmits audio to other phones.
10 Volume keys Adjust the volume of the handset, headset, speaker, and ringer.
11 Mute key Mutes local audio during calls and conferences.
12 Speakerphone
key
Enables you to place and receive calls using the speakerphone.
13 Headset key Enables you to place and receive calls through a headset.
14 Navigation
keys / Select
key
Scrolls through information or options displayed on the phone's screen. Selects
a field of displayed data.
15 Home key Displays the Home screen from other screens and displays the Lines and Calls
screen from the Home screen.
16 Line keys Enable you to select a phone line, view calls on a line, or quickly call a favorite
contact.
17 Screen Shows a 8.89 cm (3.5 in) color screen with a backlight that enables you to view
menu options and data.
18 Message
Waiting
Indicator
Flashes red to indicate when you have new messages.
19 USB Port Enables you to attach a USB flash drive or USB headset.
Included on VVX 401/411 only.
VVX 500 Series and VVX 600 Series Hardware
The following figure displays the hardware features on the VVX 500, 501, 600, and 601 business media
phones. The table lists each feature numbered in the figure.
Getting Started with VVX Business Media Phones
Polycom, Inc. 18
