QL-300 User Guide 410

Calibration

Links

Item Description

Normal Setting Adjusts the density of each color and other print quality settings.

Customize Menu Used to perform density and registration adjustment.

Item Description

Links Displays links configured by the administrator and links config-

ured by the manufacturer.

Default Chapter8
- Table of Contents8
