Part Names and Functions

QL-300 User Guide 63

Printer Exit

# Part Description

1 Fuser and Exit Unit Handle Pull upwards when removing the fuser

and exit unit.

2 Exit Feed Cover Open when clearing a paper jam.

3 Release Lever Press downwards when opening the

exit feed cover.
