Settings for the Entire FANTOM
170170
Parameter Value Explanation
Click Sound
Selects the click sound.
TYPE1
Conventional metronome sound (rst
beat is a bell)
TYPE2 Click sound
TYPE3 Beep sound
TYPE4 Cowbell sound
Click Accent
Switch
OFF, ON Adds an accent to the click sound.
Click Output
Assign
MAIN, SUB
Species whether the click sound is
output from the MAIN OUTPUT jacks
(MAIN) or from the SUB OUT jack
(SUB).
Note Pad Settings
(NOTE PAD)
Parameter Value Explanation
Zone
Pad1 Zone–
Pad16 Zone
ZONE1–16
Species the zone to which note
messages are sent when you strike the
pads.
Note Number
Pad1 Note
Number–
Pad16 Note
Number
0 (C-)–127 (G9)
Species the note number of the note
messages that are sent when you
strike the pads.
Velocity
Pad1
Velocity–
Pad16
Velocity
OFF, 1–127
Species the velocity of the note
messages that are sent when you
strike the pads.
Control Function Settings
(CONTROL)
Parameter Value Explanation
Control
Source Select
SYS
Use System Control Source 1–4 for
tone control.
SCENE
Use the scene’s Tone Control Source
1–4 settings for tone control.
System
Control
Source1–4
OFF, CC01–31,
33–95, BEND,
AFT
Specify the MIDI messages that will be
used as system controls.
System Control settings allow you to
specify MIDI messages that will apply
in common to the entire FA, and can
be used for controlling volume, tone,
etc.
You can assign up to four MIDI
messages for this type of control. If
you want to make assignments for
realtime control of the sound and
eects for each tone independently,
use “Matrix CTRL” or “MFX CTRL” For
details, refer to the “Parameter Guide”
(PDF).
Information About the FANTOM Itself
(INFO)
Here you can view the software version of the FANTOM.
Display Explanation
Version Displays the FANTOM’s software version.
Build Displays the FANTOM’s software build.
