Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-4
6.2.2 Station String Data (8-bit ASCII Char - 2/Word)
Code R/W Description Range Register (MB)
STAG
R
Station Tag 12 ASCII Char 40101-40106
CFNR
R
Configuration File Name Reduced 8 ASCII Char n/a
CFN
R
Configuration File Name 20 ASCII Char 40107-40116
SN
R
Station Serial No. 8 ASCII 40117-40120
Spares 0($0000) 40121-40199
6.2.3 Station Coil Data (1-bit)
Code R/W Description Range Coil (MB)
ASE
R
1-Active Station Event 1/0 00001
SEN
R/W
1-Station Event Not Ackl’d 1/0 00002
FSB
R
1- Flashing Station Bargraph 1/0 00003
SDV
R
1- Station Database Valid 1/0 00004
CCL
R
Config Change Counter LSB (bit) 1/0 n/a
CCH
R
Config Change Counter MSB (bit) 1/0 n/a
SCH
R
1-Station Configuration Hold 1/0 00007
SRB
R/W
1-Station Run Bit 1/0 00008
OOS
R/W
1-Station Alarms Out of Service 1/0 00009
(spares) 0 00010-00014
CC1
R/W
Config Change Bit #1 1/0 n/a
CC2
R/W
Config Change Bit #2 1/0 n/a
CC3
R/W
Config Change Bit #3 1/0 n/a
SEB
R
1-Station Error Bit 1/0 00015
(spare)
0
00016
spares 0($0000) 00017-00071
