Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-6
6.3.2 Variable Loop Integer Data
Controller [ODC]
Code R/W Description Range Register (MB)
L#TSPI R/W Target Setpoint (%) -3.3 to 103.3 ($0-$0FFF) 40451+30(#-1)
L#HLI R/W Setpoint High Limit (%) -3.3 to 103.3 ($0-$0FFF) 40452+30(#-1)
L#LLI R/W Setpoint Low Limit (%) -3.3 to 103.3 ($0-$0FFF) 40453+30(#-1)
L#RTI R/W Setpoint Ramp Time (min) 0-3840($0080-$0F80) 40454+30(#-1)
L#RRI R/W Setpoint Ramp Rate (%/min) -3.3 to 103.3 ($0-$0FFF) 40455+30(#-1)
L#A1LI R/W Alarm 1 Limit (%) -3.3 to 103.3 ($0-$0FFF) 40456+30(#-1)
L#A2LI R/W Alarm 2 Limit (%) -3.3 to 103.3 ($0-$0FFF) 40457+30(#-1)
L#A3LI R/W Alarm 3 Limit (%) -3.3 to 103.3 ($0-$0FFF) 40458+30(#-1)
L#A4LI R/W Alarm 4 Limit (%) -3.3 to 103.3 ($0-$0FFF) 40459+30(#-1)
L#T1mI R/W Tot. Preset 1 - 3 ms whole digits 0-999 ($0000-$03E7) 40460+30(#-1)
L#T1lI R/W Tot. Preset 1 - 3 ls whole digits 0-999 ($0000-$03E7) 40461+30(#-1)
L#T2mI R/W Tot. Preset 2 - 3 ms whole digits 0-999 ($0000-$03E7) 404621+30(#-1)
L#T2lI R/W Tot. Preset 2 - 3 ls whole digits 0-999 ($0000-$03E7) 40463+30(#-1)
L#A1TI R/W Alarm 1 Type 0-6 ($0000-$0006) 40464+30(#-1)
L#A2TI R/W Alarm 2 Type 0-6 ($0000-$0006) 40465+30(#-1)
L#A3TI R/W Alarm 3 Type 0-6 ($0000-$0006) 40466+30(#-1)
L#A4TI R/W Alarm 4 Type 0-6 ($0000-$0006) 40467+30(#-1)
L#A1PI R/W Alarm 1 Priority 1-5 ($0001-$0005) 40468+30(#-1)
L#A2PI R/W Alarm 2 Priority 1-5 ($0001-$0005) 40469+30(#-1)
L#A3PI R/W Alarm 3 Priority 1-5 ($0001-$0005) 40470+30(#-1)
L#A4PI R/W Alarm 4 Priority 1-5 ($0001-$0005) 40471+30(#-1)
L#CAI R/W Controller Action 1-DIR, 0-REV 40472+30(#-1)
(spare) 0 ($0000) 40473+30(#-1)
….. ….. ….. ….. …..
(spare) 0 ($0000) 40480+30(#-1)
Sequencer [ODS] - (MASK Configurations)
Code R/W Description Range Register (MB)
L#S001G0I R/W Step 1 Group 0 Input Mask $0000-$FFFF 40451+30(#-1)
L#S001G0O R/W Step 1 Group 0 Output Mask $0000-$FFFF 40452+30(#-1)
L#S001G1I R/W Step 1 Group 1 Input Mask $0000-$FFFF 40453+30(#-1)
L#S001G1O R/W Step 1 Group 1 Output Mask $0000-$FFFF 40454+30(#-1)
L#S001G2I R/W Step 1 Group 2 Input Mask $0000-$FFFF 40455+30(#-1)
L#S001G2O R/W Step 1 Group 2 Output Mask $0000-$FFFF 40456+30(#-1)
L#S002G0I R/W Step 2 Group 0 Input Mask $0000-$FFFF 40457+30(#-1)
L#S002G0O R/W Step 2 Group 0 Output Mask $0000-$FFFF 40458+30(#-1)
….. ….. ….. ….. …..
L#S005G0O R/W Step 5 Group 0 Output Mask $0000-$FFFF 40476+30(#-1)
L#S005G1I R/W Step 5 Group 1 Input Mask $0000-$FFFF 40477+30(#-1)
L#S005G1O R/W Step 5 Group 1 Output Mask $0000-$FFFF 40478+30(#-1)
L#S005G2I R/W Step 5 Group 2 Input Mask $0000-$FFFF 40479+30(#-1)
L#S005G2O R/W Step 5 Group 2 Output Mask $0000-$FFFF 40480+30(#-1)
