13.2 ACCESSORIES
The following two tables list the accessories currently available.
ACCESSORY PART NUMBER DESCRIPTION
i|config Graphical
Configuration Utility
iCONFIG-Vn.nn Windows® 98, NT, 2000, and XP compatible software for
PC-based controller configuration and creation of a function
block diagram. Transfer configuration to and from
controller via Modbus or Ethernet.
Vn.nn - the latest software version will be supplied.
Includes:
16353-61 Cable - see description below
16353-63 Adapter - see description below
Transmitter Power Supply 15124-1 Acopian Model B24G210M, 24 Vdc, 2.0A
Adapter Bezel 15738-123 A panel cutout adapter for mounting a controller in a 3"x 6"
panel cutout.
Blank Filler Panel 15738-168 Enhances control room appearance by covering a panel
cutout intended for future mounting of a controller.
Loop Identification Card ----- Custom printed loop identification for flip-down access
door. Specify up to 5 lines with 24 characters per line.
Permanent Instrument Tag ----- Stainless steel tag permanently attached to the controller
case. One line with up to 24 characters can be specified.
Display Assembly Remote
Mounting Kit
16353-54 For remote panel mounting of a Display Assembly. Includes:
Flange Assembly
Mounting Clips and Screws
Display (Ribbon) Cable, 48 inches (1219 mm) long
Installation Instruction
Does not include the Display Assembly.
Communications Cable,
MMJ11 to MMJ11
16353-61 Connects MMJ11 on adapter (connected to a personal
computer’s serial port) to MMJ11 on a Display Assembly.
Select one of the following adapters.
Adapter, DB25 to MMJ11
Adapter, DB9 to MMJ11
16353-62
16353-63
Adapts personal computer serial port to above
Communications Cable.
Faceplate Labels ----- Discontinued.
13.3 SERVICE PARTS KITS
Exploded view drawings of the Siemens 353 appear in Section 1 Introduction and Section 10 Maintenance.
SERVICE PART DESCRIPTION PART NO.
MultiMediaCard TGX:16353-304
- FIRMWARE UPDATE KITS -
Controller upgrade Utility and Controller Firmware for Models 352P, 353, 353R,
354 and IPAC
Download file fw400.zip, the file/firmware revision at the time this manual was
prepared, or order a firmware CD
15939-71V4.00
Contact Siemens
for current
version.

Siemens 353 Specifications

General

Brand	Siemens
Model	353
Category	Controller
Language	English
