Siemens 353 User Manual

UM353-1B Data Mapping
April 2012
6-23
6.3.11 Trend Data (Loop Defined by MLTP)
Code
R/W Description Range Register (MB)
A1RMN R ATD01 MIN SCALE Real 48001
A1RMX R ATD01 MAX SCALE Real 48003
A1DPP R ATD01 Decimal Point Position 0-5 48005
A1EU R ATD01 Engineering Units 6 ASCII Char 48006
A1YR R ATD01 Year V2.0 (5) 1997- 48009
A1MT R ATD01 Month V2.0 (5) 1-12 48010
A1DY R ATD01 Day V2.0 (5) 1-31 48011
A1HR R ATD01 Hour V2.0 (5) 0-23 48012
A1MN R ATD01 Minute V2.0 (5) 0-59 48013
A1SC R ATD01 Second V2.0 (5) 0-59 48014
A1ST R/W* ATD01 Sample Time x0.01=min 1-48000 48015
A1STC R ATD01 % Sample Time Complete 0-1000 (x.1=%) 48016
A1D1 R ATD01 Data 1 (latest) 0-100% 128-3968 48017
A1D2 R ATD01 Data 2 0-100% 128-3968 48018
A1D3 R ATD01 Data 3 0-100% 128-3968 48019
....................................................................................................................................................................
A1D168 R ATD01 Data 168 0-100% 128-3968 48184
A1D169 R ATD01 Data 169 0-100% 128-3968 48185
A1D170 R ATD01 Data 170 0-100% 128-3968 48186
* Writing to the sample time will reset all data points A1D1 through A1D170 to $0.
A2RMN R ATD02 MIN SCALE Real 48201
A2RMX R ATD02 MAX SCALE Real 48203
A2DPP R ATD02 Decimal Point Position 0-5 48205
A2EU R ATD02 Engineering Units 6 ASCII Char 48206
A2YR R ATD02 Year V2.0 (5) 1997 48209
A2MT R ATD02 Month V2.0 (5) 1-12 48210
A2DY R ATD02 Day V2.0 (5) 1-31 48211
A2HR R ATD02 Hour V2.0 (5) 0-23 48212
A2MN R ATD02 Minute V2.0 (5) 0-59 48213
A2SC R ATD02 Second V2.0 (5) 0-59 48214
A2ST R/W* ATD02 Sample Time x0.01=min 1-48000 48215
A2STC R ATD02 % Sample Time Complete 0-1000 (x.1=%) 48216
A2D1 R ATD02 Data 1 (latest) 0-100% 128-3968 48217
A2D2 R ATD02 Data 2 0-100% 128-3968 48218
A2D3 R ATD02 Data 3 0-100% 128-3968 48219
....................................................................................................................................................................
A2D168 R ATD02 Data 168 0-100% 128-3968 48384
A2D169 R ATD02 Data 169 0-100% 128-3968 48385
A2D170 R ATD02 Data 170 0-100% 128-3968 48386
* Writing to the sample time will reset all data points A2D1 through A2D170 to $0.
