Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-10
6.3.5 Variable Loop Floating Point Data (32-bit IEEE)
Controller [ODC]
Code
R/W Description Range Register (MB)
L#TSPF R/W Target Setpoint Real 42451+60(#-1)
L#HLF R/W Setpoint High Limit Real 42453+60(#-1)
L#LLF R/W Setpoint Low Limit Real 42455+60(#-1)
L#RTF R/W Setpoint Ramp Time (min) Real 42457+60(#-1)
L#RRF R/W Setpoint Ramp Rate (units/min) Real 42459+60(#-1)
L#A1LF R/W Alarm 1 Limit Real 42461+60(#-1)
L#A2LF R/W Alarm 2 Limit Real 42463+60(#-1)
L#A3LF R/W Alarm 3 Limit Real 42465+60(#-1)
L#A4LF R/W Alarm 4 Limit Real 42467+60(#-1)
L#T1F R/W Totalizer Preset 1 Real 42469+60(#-1)
L#T2F R/W Totalizer Preset 2 Real 42471+60(#-1)
L#Q1F R/W Quickset Hold 1 Real 42473+60(#-1)
L#Q2F R/W Quickset Hold 2 Real 42475+60(#-1)
L#BHLF R/W Batch Switch High Limit Real 42477+60(#-1)
L#BLLF R/W Batch Switch Low Limit Real 42479+60(#-1)
L#BPLF R/W Batch Switch Pre-Load Real 42481+60(#-1)
L#BGF R/W Batch Switch Gain Real 42483+60(#-1)
(spares) ($00000000) 42485-42509+60(#-1)
Sequencer (Timers - Running Values) [ODS]
Code
R/W Description Range Register (MB)
L#DYT01ET R DYT01 Elapsed Time Real 42451+60(#-1)
L#DYT01RT R/W DYT01 Remaining Time Real 42453+60(#-1)
L#OST01ET R OST01 Elapsed Time Real 42455+60(#-1)
L#OST01RT R/W OST01 Remaining Time Real 42457+60(#-1)
L#RCT01ET R RCT01 Elapsed Time Real 42459+60(#-1)
L#RCT01RT R/W RCT01 Remaining Time Real 42461+60(#-1)
L#ROT01ET R ROT01 Elapsed Time Real 42463+60(#-1)
L#ROT01RT R/W ROT01 Remaining Time Real 42465+60(#-1)
L#DYT02ET R DYT02 Elapsed Time Real 42467+60(#-1)
L#DYT02RT R/W DYT02 Remaining Time Real 42469+60(#-1)
L#OST02ET R OST02 Elapsed Time Real 42471+60(#-1)
L#OST02RT R/W OST02 Remaining Time Real 42473+60(#-1)
L#RCT02ET R RCT02 Elapsed Time Real 42475+60(#-1)
L#RCT02RT R/W RCT02 Remaining Time Real 42477+60(#-1)
L#ROT02ET R ROT02 Elapsed Time Real 42479+60(#-1)
L#ROT02RT R/W ROT02 Remaining Time Real 42481+60(#-1)
L#DYT03ET R DYT03 Elapsed Time Real 42483+60(#-1)
L#DYT03RT R/W DYT03 Remaining Time Real 42485+60(#-1)
L#OST03ET R OST03 Elapsed Time Real 42487+60(#-1)
L#OST03RT R/W OST03 Remaining Time Real 42489+60(#-1)
L#RCT03ET R RCT03 Elapsed Time Real 42491+60(#-1)
L#RCT03RT R/W RCT03 Remaining Time Real 42493+60(#-1)
L#ROT03ET R ROT03 Elapsed Time Real 42495+60(#-1)
L#ROT03RT R/W ROT03 Remaining Time Real 42497+60(#-1)
(spares) 42499-42509+60(#-1)
