UM353-1B Data Mapping
April 2012
6-13
6.3.7 String Loop Data (8-bit ASCII Char - 2/Word)
Controller [ODC]
Code
R/W Description Range Register (MB)
L#TAG R Loop Tag 12 ASCII Char 45451+100(#-1)
L#PUR R/W Process Units - Reduced 4 ASCII Char 45457+100(#-1)
L#PU R/W Process Units 6 ASCII Char 45459+100(#-1)
L#VU R/W Valve Units 6 ASCII Char 45462+100(#-1)
L#XU R/W X Variable Units 6 ASCII Char 45465+100(#-1)
L#YU R/W Y Variable Units 6 ASCII Char 45468+100(#-1)
L#TLU R/W Totalizer Units 6 ASCII Char 45471+100(#-1)
L#Q1N R Quickset Hold 1 Name 8 ASCII Char 45474+100(#-1)
L#Q1U R/W Quickset Hold 1 Units 6 ASCII Char 45478+100(#-1)
L#Q2N R Quickset Hold 2 Name 8 ASCII Char 45481+100(#-1)
L#Q2U R/W Quickset Hold 2 Units 6 ASCII Char 45485+100(#-1)
L#LHM R/W Left Horizontal Bar Message 5 ASCII Char 45488+100(#-1)
L#RHM R/W Right Horizontal Bar Message 5 ASCII Char 45491+100(#-1)
(spares) ($0000) 45492-45550+100(#-1)
Sequencer [ODS]
Code
R/W Description Range Register (MB)
L#TAG R Loop Tag) 12 ASCII Char 45451+100(#-1)
L#PMSG R Primary Message 8 ASCII Char 45457+100(#-1)
L#SMSG R Secondary Message 12 ASCII Char 45461+100(#-1)
L#CMSGa R Conditional Message a * 16 ASCII Char 45467+100(#-1)
L#CMSGb R Conditional Message b * 16 ASCII Char 45475+100(#-1)
L#CMSGc R Conditional Message c * 16 ASCII Char 45483+100(#-1)
L#CMSGd R Conditional Message d * 16 ASCII Char 45491+100(#-1)
L#CMSGe R Conditional Message e * 16 ASCII Char 45499+100(#-1)
L#CMSGf R Conditional Message f * 16 ASCII Char 45507+100(#-1)
L#CMSGg R Conditional Message g * 16 ASCII Char 45515+100(#-1)
L#CMSGh R Conditional Message h * 16 ASCII Char 45523+100(#-1)
L#CMSGi R Conditional Message I * 16 ASCII Char 45531+100(#-1)
L#RMSG R Recipe Message 12 ASCII Char 45539+100(#-1)
(spares) ($0000) 45545-45550+100(#-1)
* Conditional messages are stacked in the order of occurrence. The 9 most recent active conditional messages can
be viewed.
