UM353-1B Data Mapping
April 2012
6-11
Analog Indicator [ODA]
Code
R/W Description Range Register (MB)
L#P1ALF R/W Process 1 Alarm A Limit Real 42451+60(#-1)
L#P1BLF R/W Process 1 Alarm B Limit Real 42453+60(#-1)
L#P2ALF R/W Process 2 Alarm A Limit Real 42455+60(#-1)
L#P2BLF R/W Process 2 Alarm B Limit Real 42457+60(#-1)
L#P3ALF R/W Process 3 Alarm A Limit Real 42459+60(#-1)
L#P3BLF R/W Process 3 Alarm B Limit Real 42461+60(#-1)
L#P4ALF R/W Process 4 Alarm A Limit Real 42463+60(#-1)
L#P4BLF R/W Process 4 Alarm B Limit Real 42465+60(#-1)
L#Q1F R/W Quickset Hold 1 Real 42467+60(#-1)
L#Q2F R/W Quickset Hold 2 Real 42469+60(#-1)
L#Q3F R/W Quickset Hold 3 Real 42471+60(#-1)
L#Q4F R/W Quickset Hold 4 Real 42473+60(#-1)
(spares) ($00000000) 42475-42509+60(#-1)
6.3.6 Static Loop Floating Point Data (32-bit IEEE)
Controller [ODC]
Code
R/W Description Range Register (MB)
L#PGF R/W Proportional Gain 0.001 - 100.0 43951+60(#-1)
L# TIF R/W Integral Time 0.001 - 4000.0 min 43953+60(#-1)
L#TDF R/W Derivative Time 0.00 - 100.00 min 43955+60(#-1)
L#MRF R/W Manual Reset 0.00 - 100.00 43957+60(#-1)
L#ADF R/W Autotune Deviation auto(0), 2.5-25% 43959+60(#-1)
L#AHF R/W Autotune Hysteresis auto(0), 0.5 - 10.0% 43961+60(#-1)
L#ASF R/W Autotune Step (initial) 5 - 40% 43963+60(#-1)
L#APGF R Autotune Proportional Gain 0.001 - 1000.0 43965+60(#-1)
L#ATIF R Autotune Integral Time 0.001 - 4000.0 min 43967+60(#-1)
L#ATDF R Autotune Derivative Time 0.00 - 100.00 min 3969+60(#-1)
L#HDF R/W On-Off Controller HI Deviation Real 43971+60(#-1)
L#LDF R/W On-Off Controller LO Deviation Real 43973+60(#-1)
L#DBF R/W On-Off Controller DEADBAND Real 43975+60(#-1)
L#PMNF R/W Process MIN SCALE Real 43977+60(#-1)
L#PMXF R/W Process MAX SCALE Real 43979+60(#-1)
L#VMNF R/W Valve MIN SCALE Real 43981+60(#-1)
L#VMXF R/W ValveMAX SCALE Real 43983+60(#-1)
L#XMNF R/W X Variable MIN SCALE Real 43985+60(#-1)
L#XMXF R/W X Variable MAX SCALE Real 43987+60(#-1)
L#YMNF R/W Y Variable MIN SCALE Real 43989+60(#-1)
L#YMXF R/W Y Variable MAX SCALE Real 43991+60(#-1)
L#Q1MNF R/W Quickset 1 MIN SCALE Real 43993+60(#-1)
L#Q1MXF R/W Quickset 1 MAX SCALE Real 43995+60(#-1)
L#Q2MNF R/W Quickset 2 MIN SCALE Real 43997+60(#-1)
L#Q2MXF R/W Quickset 2 MAX SCALE Real 44009+60(#-1)
L#DGF R/W Derivative Gain 1.00 - 30.00 44001+60(#-1)
(spares) ($00000000) 44003-44009+60(#-1)
