Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-8
6.3.3 Static Loop Integer Data
Controller [ODC]
Code R/W Description Range Register (MB)
L#PGI R/W Proportional Gain -9.99 to -0.01 ($1419-$17FF)
0.01 to 9.99 ($1801$1BE7)
-100.0 to -10.0 ($2418-$279C)
10.0 to 100.0 ($2864-$2BE8)
41201+30(#-1)
L#TII R/W Integral Time (min) 0.01 to 9.99 ($2081-$2467)
10.0 to 99.9 ($10E4-$1467)
100 to 3967 ($30E4-$3FFF)
41202+30(#-1)
L#TDI R/W Derivative Time (min) 0.00 to 9.99 ($2080-$2467)
10.0 to 100.0 ($10E4-$1468)
41203+30(#-1)
L#DGI R/W Derivative Gain 1.00 to 39.67 ($20E4--$2FFF) 41204+30(#-1)
L#MRI R/W Manual Reset (%) 0.0 to 100.0 ($0080-$0F80) 41205+30(#-1)
L#RHI R Range High -1 to -32768 ($FFFF-$8000)
0 to 32767 ($0000-$7FFF)
41206+30(#-1)
L#RLI R Range Low -1 to -32768 ($FFFF-$8000)
0 to 32767 ($0000-$7FFF)
41207+30(#-1)
L#DPPI R Decimal Point Position 0 to 5 ($0000-$0005) 41208+30(#-1)
L#PDPPI R Process DPP 0 to 5 ($0000-$0005) 41209+30(#-1)
L#VDPPI
R Valve DPP 0 to 5 ($0000-$0005) 41210+30(#-1)
L#XDPPI
R Variable X DPP 0 to 5 ($0000-$0005) 41211+30(#-1)
L#YDPPI
R Variable Y DPP 0 to 5 ($0000-$0005) 41212+30(#-1)
(spare) 0 ($0000) 41213+30(#-1)
….. …..
….. ….. …..
(spare) 0 ($0000) 41230+30(#-1)
Sequencer [ODS] - (MASK Configurations)
Code R/W Description Range Register (MB)
L#S006G0I R/W Step 6 Group 0 Input Mask $0000-$FFFF 41201+30(#-1)
L#S006G0O R/W Step 6 Group 0 Output Mask $0000-$FFFF 41202+30(#-1)
L#S006G1I R/W Step 6 Group 1 Input Mask $0000-$FFFF 41203+30(#-1)
L#S006G1O R/W Step 6 Group 1 Output Mask $0000-$FFFF 41204+30(#-1)
L#S006G2I R/W Step 6 Group 2 Input Mask $0000-$FFFF 41205+30(#-1)
L#S006G2O R/W Step 6 Group 2 Output Mask $0000-$FFFF 41206+30(#-1)
L#S007G0I R/W Step 7 Group 0 Input Mask $0000-$FFFF 41207+30(#-1)
L#S007G0O R/W Step 7 Group 0 Output Mask $0000-$FFFF 41208+30(#-1)
….. ….. ….. ….. …..
L#S009G2I R/W Step 9 Group 2 Input Mask $0000-$FFFF 41223+30(#-1)
L#S009G2O R/W Step 9 Group 2 Output Mask $0000-$FFFF 41224+30(#-1)
L#S010G0I R/W Step 10 Group 0 Input Mask $0000-$FFFF 41225+30(#-1)
L#S010G0O R/W Step 10 Group 0 Output Mask $0000-$FFFF 41226+30(#-1)
L#S010G1I R/W Step 10 Group 1 Input Mask $0000-$FFFF 41227+30(#-1)
L#S010G1O R/W Step 10 Group 1 Output Mask $0000-$FFFF 41228+30(#-1)
L#S010G2I R/W Step 10 Group 2 Input Mask $0000-$FFFF 41229+30(#-1)
L#S010G2O R/W Step 10 Group 2 Output Mask $0000-$FFFF 41230+30(#-1)
