7.5 FACTORY CALIBRATION
Unless a special calibration is ordered, the factory calibration is as follows:
Table 7-2 Factory Calibration
ANALOG INPUT OR OUTPUT FACTORY CALIBRATION
Analog input function blocks 1 to 5 Vdc
Analog output function blocks 4 to 20 mA
Thermocouple Type J, Upscale Break
RTD CAL ZERO - 0°C
CAL FULL - 500°C
CAL VIEW - -3.3 to 103.3%
Slidewire CAL ZERO - 0%
CAL FULL - 100%
CAL VIEW - Contact factory
Ohms CAL ZERO - 0 Ohms
CAL FULL - 5000 Ohms
CAL VIEW - Contact factory
Millivolt CAL ZERO - -19.0 mV
CAL FULL - +19.0 mV
CAL VIEW - 0% TO 100%
Section 11.0 provides calibration procedures that may be used to check or change factory calibration.
