Siemens 353 User Manual

Data Mapping UM353-1B
April 2012
6-26
6.3.12 Configuration Data Sequencer Loop
The Modbus registers on this page refer to configuration parameters of function blocks within a specific loop
previously defined by Modbus parameter MSLCP (40048). For example, to read or write the Step 1 Group 0 Input
Mask for the PRSEQ block that is in a loop with a Modbus Index of 3, write a 3 to 40048, then read or write to
register 410001.
Sequencer (MASK Configurations)
Code
`R/W Description Range Register (MB)
S001G0I R/W Step 1 Group 0 Input Mask $0000-$FFFF 410001
S001G0O R/W Step 1 Group 0 Output Mask $0000-$FFFF 410002
S001G1I R/W Step 1 Group 1 Input Mask $0000-$FFFF 410003
S001G1O R/W Step 1 Group 1 Output Mask $0000-$FFFF 410004
S001G2I R/W Step 1 Group 2 Input Mask $0000-$FFFF 410005
S001G2O R/W Step 1 Group 2 Output Mask $0000-$FFFF 410006
S001G3I R/W Step 1 Group 3 Input Mask $0000-$FFFF 410007
S001G3O R/W Step 1 Group 3 Output Mask $0000-$FFFF 410008
.........................................................................................................................................................................................
S250GEI R/W Step 250 Group E Input Mask $0000-$FFFF 417997
S250GEO R/W Step 250 Group E Output Mask $0000-$FFFF 417998
S250GFI R/W Step 250 Group F Input Mask $0000-$FFFF 417999
S250GFO R/W Step 250 Group F Output Mask $0000-$FFFF 418000
Real TimeTrip Block Configurations
Code
R/W Description Range Register (MB)
RTT01Y R/W Year 1999- 419001
RTT01M R/W Month 1-12 419002
RTT01D R/W Day 1-31 419003
RTT01HR R/W Hour 0-23 419004
RTT01MN R/W Minute 0-59 419005
RTT01SC R/W Second 0-59 419006
RTT01DA R/W Day 0000 0000 0SMT WTFS 419007
RTT02Y R/W Year 1999- 419008
RTT02M R/W Month 1-12 419009
RTT02D R/W Day 1-31 419010
RTT02HR R/W Hour 0-23 419011
RTT02MN R/W Minute 0-59 419012
RTT02SC R/W Second 0-59 419013
RTT02DA R/W Day 0000 0000 0SMT WTFS 419014
RTT03Y R/W Year 1999- 419015
RTT03M R/W Month 1-12 419016
RTT03D R/W Day 1-31 419017
RTT03HR R/W Hour 0-23 419018
RTT03MN R/W Minute 0-59 419019
RTT03SC R/W Second 0-59 419020
RTT03DA R/W Day 0000 0000 0SMT WTFS 419021
