3.2.44 ID - ID Controller
ID is an integral only controller and one of five controller
types that can be used on a one per loop basis. It uses
external feedback to provide integral action and, therefore,
allows interaction with other function blocks or external
devices, such as pneumatic controllers and shutoff
switches while eliminating windup that can occur with
other controller types. Derivative action is provided when
the parameter TD is non-zero.
When input A is high (1), the controller will operate in the
normal auto mode and when low (0) will cause the output
of the lag function to track the feedback signal. This will
cause the controller output to track the feedback within the
limits. When the controller is switched back to auto, the
value at the input of the lag (GE+FB), if the GE is non-
zero, will cause the output to integrate to a new output at
the TI time constant.
The process range pointer parameter points to a function
block that has range scaling, such as the analog input that
is providing the process variable signal. This enables the
controller to normalize the tuning parameters for the range
of the process input. If this parameter is not configured, the controller will use a range scaling of 0.00 - 100.00.
POWER UP - During a warm or cold start, the output will be initialized to the value of the MINSCALE parameter
and all dynamic states will be initialized to their current input value on the first scan cycle.
