Commissioning (software)
6.4 Configuring a CX32-2
SIMOTION D4x5-2
200 Commissioning and Hardware Installation Manual, 02/2012
6.4.5 CX32-2 offline configuration
Options
The following options are available for commissioning a project created offline:
● Loading a project created offline to the target system
● Loading a project created offline to the CompactFlash Card
6.4.5.1 Loading a project created offline to the target system
Requirement
● Your project, including all SINAMICS Integrated and CX32-2 drive components, must
have been configured already (see Preparing for configuration (Page 196)).
● The act
ual topology must correspond with the reference topology.
Note
A step-by-step commissioning with the CX32-2 controller extension is described below.
In a step-by-step procedure, first the D4x5-2, then the SINAMICS Integrated and finally
each CX32-2 is commissioned. This step-by-step procedure is not mandatory, but has
the advantage that the location and cause of an error are easier to identify.
Procedure
1. Deselect all target devices, with the exception of the SIMOTION D4x5-2, using the
"Target system" > "Select target devices" menu command in SCOUT.
2. Go online with the D4x5-2 by clicking "Connect to selected target devices".
3. Select the D4x5-2 in the project tree. Load the configuration to the SIMOTION D4x5-2
with "Download CPU / drive unit to target device".
4. Copy the configuration from RAM to ROM with "Copy RAM to ROM".
5. Select "Connect target device" in the SINAMICS Integrated context menu. You will then
be connected to the SINAMICS Integrated online.
6. Load the parameterization by selecting "Target device" > "Download" in the SINAMICS
Integrated context menu.
7. Copy the parameterization from RAM to ROM with "Copy RAM to ROM".
8. Then select "Load CPU / drive unit to PG" to load the parameterization from the
SINAMICS Integrated back to the programming device in order to back up the SINAMICS
parameter calculations.
