Commissioning (software)
6.13 Configuration of the technology objects and I/O variables
SIMOTION D4x5-2
262 Commissioning and Hardware Installation Manual, 02/2012
6.13 Configuration of the technology objects and I/O variables
6.13.1 Configuration of global measuring inputs
Overview
The type of measuring input must be selected during the configuration of the TO
measuringInput.
The following measuring input types are available:
Table 6- 12 Measuring input types
Measuring input types Explanation
Standard (global measuring input) Compared with the drive-related local measuring inputs,
global measuring inputs have extended functionality and
also support a symbolic configuration.
They are therefore set as standard.
Drive-related (local measuring input) The drive-related local measuring inputs are configured
via drive parameters, see Section Configuration of drive-
related I/Os (without symbolic assignment) (Page 373) (in
the appendix).
Listening measuring input Through the configuration of a listening measuring input,
measuring can be performed simultaneously on several
axes or external encoders with one measuring input.
Detailed information can be found in the
SIMOTION
Motion Control Output Cams and Measuring Inputs
Function Manual.
A detailed comparison of "local" and "global" measuring inputs as well as an overview of
which modules support local or global measuring inputs can be found in the appendix in
Section Configuration of drive-related I/Os (without symbolic assignment) (Page 373).
Procedure
If a global measuring input is selected, it must be assigned a hardware input.
To do this, open the assignment dialog box via
and select a free (i.e. not yet used) I/O.
Note
Only those I/Os are displayed that have the appropriate measuring input functionality (MI_xx
[channel name, terminal number]). If no suitable I/Os are displayed, you must first configure
the I/Os (I/O must be configured as "measuring input")
