Connecting
3.6 Connecting I/Os
SIMOTION D4x5-2
58 Commissioning and Hardware Installation Manual, 02/2012
3.6 Connecting I/Os
Connection cables for the I/Os of the D4x5-2, CX32-2 and TB30
The following conditions apply to connection cables:
● Use flexible cables with a cable cross-section
– of minimum 0.25 mm
2
and maximum 1.5 mm
2
(D4x5-2, CX32-2)
– of minimum 0.25 mm
2
and maximum 0.5 mm
2
(TB30)
● Ferrules are not mandatory.
● You can use ferrules without an insulating collar in accordance with DIN 46228, Form A
long version.
Note
To achieve optimum interference immunity, shielded cables must be used for connecting
analog signals, measuring inputs or external zero marks.
Tools required
Screwdriver with 2 mm blade width.
Wiring inputs/outputs
1. Strip off 8 mm of cable insulation and, if necessary, press on a ferrule.
2. Wire the digital inputs and outputs for connection of the sensors and actuators.
3. Insert the cable into the appropriate spring-loaded terminal. This is easier when you use
the screwdriver to push back the spring.
Additional references
For further information on cabling options (e.g. the use of rigid cables) and the pin
assignment of the I/O interfaces, see the
SIMOTION D4x5-2
Manual:
● Section "Interfaces" for the I/O interfaces of the D4x5-2
● Section "Supplementary system components -> Interfaces" for the I/O interfaces of the
CX32-2/TB30
