Parameter Function Parameter values Unit
50.PRST Preset
Reset all parameters which
can be reset by 'Init', 'PArA'
and 'diAg'.
ALL
Reset initialization parame‐
ters '1.YFCT' to '5.INITM'.
Init
Reset parameters '6.SCUR' to
'49. LIM'.
PArA
Reset parameters A to U of
the extended diagnostics func‐
tion as well as parameter
'52.XDIAG'.
diAg
51.PNEUM Pneumatics type
Standard pneumatic block Std
Fail in place pneumatic block FIP
Operation with boosters booSt
52.XDIAG Activation of extended diagnostics
Off OFF
Single stage message On1
Two stage message On2
Three stage message On3
1)
Setpoint turning points only appear when '12.SFCT = FrEE' is selected.
2)
'Normally closed' means: Operation when a switch is open or Low level
'Normally open' means: Action on switch closed or High level
3)
'Normal' means: High level, no fault message
'Inverted' means: Low level, no fault message
4)
'+' means: Logical OR combination
8.3.3 Overview of advanced diagnostic parameters A to U
Introduction
These parameters are used to set the extended diagnostics functions of the positioner.
Note
Factory setting
Factory-set parameter values are printed in bold in the following table.
Parameter assignment
8.3 Tabular overview of the parameters
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 139
