Overview parameter J
Parameter Function Parameter values Unit
J. TMAX Monitoring of upper limit temperature with the following parameters:
J1.TUNIT Temperature unit °C °F °C/°F
J2.LEVL1 Threshold 1 -40 ... 75 ... 90 -40 ... 194
J3.LEVL2 Threshold 2 -40 ... 80 ... 90 -40 ... 194
J4.LEVL3 Threshold 3 -40 ... 90 -40 ... 194
Overview parameter L
Parameter Function Parameter values Unit
L. STRK Monitoring of number of total strokes with the following parameters:
L1. LIMIT Limit 1 ... 1E6 ... 1E8
L2.FACT1 Factor 1 0.1 ... 1.0 ... 40.0
L3.FACT2 Factor 2 0.1 ... 2.0 ... 40.0
L4.FACT3 Factor 3 0.1 ... 5.0 ... 40.0
Overview parameter O
Parameter Function Parameter values Unit
O. DCHG Monitoring of number of changes in direction with the following parameters:
O1.LIMIT Limit 1 ... 1E6 ... 1E8
O2.FACT1 Factor 1 0.1 ... 1.0 ... 40.0
O3.FACT2 Factor 2 0.1 ... 2.0 ... 40.0
O4.FACT3 Factor 3 0.1 ... 5.0 ... 40.0
Overview parameter P
Parameter Function Parameter values Unit
P. PAVG Monitoring of position average value with the following parameters:
P1.TBASE Time basis of average value generation 0.5h / 8h / 5d / 60d / 2.5y
P2.STATE Status of monitoring of position average value IdLE / rEF / ###.# / Strt
P3.LEVL1 Threshold 1 0.1 ... 2.0 ... 100.0 %
P4.LEVL2 Threshold 2 0.1 ... 5.0 ... 100.0 %
P5.LEVL3 Threshold 3 0.1 ... 10.0 ... 100.0 %
Parameter assignment
8.3 Tabular overview of the parameters
SIPART PS2 with 4 to 20 mA/HART
142 Operating Instructions, 11/2019, A5E00074631-AE
