12.10.5 Analog Input Module (AIM) 6DR4004-6F / -8F
Without explosion
protection
With explosion protection
Ex "ia", "db ia", "ic"
With explosion protection
Ex "ec", "tb"
6DR4004-8F 6DR4004-6F 6DR4004-6F
The Analog Input Module (AIM) 6DR4004-6F and -8F is required to connect a Non-Contacting Sensor (NCS) or Position
Transmitter 6DR4004-1ES to -4ES.
For devices without explosion protection, other types of potentiometers with resistance values between 3 and 20 KΩ can be
connected.
R-potentiometer
● Peak values when supplied by other
basic devices (6DR50/1/2/3/9)
U
max
= 5 V U
o
≤ 5 V
I
o
≤ 100 mA
P
o
≤ 33 mW
C
o
≤ 1 μF
L
o
≤ 1 mH
U
max
= 5 V
● Maximum values when powered by the
base unit with PA (6DR55) or FF com‐
munication (6DR56)
U
max
= 5 V U
o
≤ 5 V
I
o
≤ 75 mA static
I
o
≤ 160 mA transient
P
o
≤ 120 mW
C
o
≤ 1 μF
L
o
≤ 1 mH
U
max
= 5 V
Signal 20 mA
● Rated signal range
0 ... 20 mA -
● Internal load R
B
200 Ω -
● Static destruction limit
40 mA -
Signal 10 V
● Rated signal range
0 ... 10 V -
● Internal resistance R
i
25 kΩ -
● Static destruction limit
20 V -
Supply and signal power circuits Galvanically connected with the basic device
12.10.6 Internal NCS module 6DR4004-5L / 6DR4004-5LE
Additional modules Without explosion protec‐
tion
With explosion protection
Ex "ia", "db ia"
With explosion protection
Ex "ic", "ec", "tb"
6DR4004-5L 6DR4004-5LE 6DR4004-5LE
Linearity (after corrections made by
positioner)
± 1 %
Hysteresis ± 0.2 %
For connecting to circuits with the fol‐
lowing peak values
- U
i
≤ 5 V
I
i
≤ 160 mA
P
i
≤ 120 mW
U
i
≤ 5 V
Effective internal capacitance - C
i
= 110 nF + 110 nF per meter of connecting cable
Effective internal inductance - L
i
= 270 µH + 6.53 µH per meter of connecting cable
