Siemens SIPART PS2 series User Manual

Type of protection 6DR5ayb-*cdef-g*Ah-Zjjj Ex marking
ATEX 205947X
IECEx TUN 17.0023X
Ex marking
FM 17US0053X
CSA 18CA70166848X
For c = E,
● a = 0, 1, 2, 3, 5, 6 and b = 5, 6
Il 2 G Ex db llC T6/T4 Gb
II 2 D Ex tb IIIC T100°C Db
FM
Cl I Zn 1 AEx db IIC Gb
XP Cl I Div 1 Gp A-D
CSA
Cl I Zn 1 Ex db IIC Gb
XP Cl I Div 1 Gp C-D
FM + CSA
Zn 21 AEx tb IIIC T100°C Db
Zn 21 Ex tb IIIC T100°C Db
DIP Cl II, III Div 1 Gp E-G
For c = F,
● a = 0, 2, 5, 6 and b = 1, 2, 3, 5, 6
● a = 1 and b = 3
Non Contacting Sensor (NCS)
● 6DR4004-6N
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
II 2 D Ex ia IIIC T130°C Db
II 3 G Ex ec IIC T6/T4 Gc
Cl I Zn 1 AEx ib IIC Gb
Cl I Zn 1 Ex ib IIC Gb
Zn 21 AEx ib IIIC T130°C Db
Zn 21 Ex ib IIIC T130°C Db
IS Cl I, II, III Div 1 Gp A-G
Cl I Zn 2 AEx nA IIC Gc
Cl I Zn 2 Ex nA IIC Gc
NI Cl I Div 2 Gp A-D
For c = G,
● a = 0, 2, 5, 6 and b = 1, 2, 3, 5, 6
● a = 1 and b = 3
II 3 G Ex ec IIC T6/T4 Gc Cl I Zn 2 AEx nA IIC Gc
Cl I Zn 2 Ex nA IIC Gc
NI Cl I Div 2 Gp A-D
For c = K and b = 1, 2, 3, 5, 6
● a = 0, 2, 5, 6 and b = 1, 2, 3, 5, 6
● a = 1 and b = 3
Position Transmitter:
● 6DR4004-1ES
● 6DR4004-2ES
● 6DR4004-3ES
● 6DR4004-4ES
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
II 2 D Ex ia IIIC T130°C Db
II 2 D Ex tb IIIC T100°C Db
II 3 G Ex ec IIC T6/T4 Gc
Cl I Zn 1 AEx ib IIC Gb
Cl I Zn 1 Ex ib IIC Gb
Zn 21 AEx ib IIIC, T130°C Db
Zn 21 Ex ib IIIC, T130°C Db
IS Cl I, II, III Div 1 Gp A-G
Cl I Zn 2 AEx nA IIC Gc
Cl I Zn 2 Ex nA IIC Gc
NI Cl I Div 2 Gp A-D
Zn 21 AEx tb IIIC T100°C Db
Zn 21 Ex tb IIIC T100°C Db
DIP Cl II, III Div 1 Gp E-G
12.5.3 Maximal permissible ambient temperature ranges
Positioner and option modules Temperature class T4 Temperature class T6
Positioner
● 6DR5ayb-0cdef-g*Ah-Z jjj
-30 °C ≤Ta ≤ +80 °C -30 °C ≤Ta ≤ +50 °C
● 6DR5ayb-0cdef-g*Ah-Z M40
-40 °C ≤Ta ≤ +80 °C -40 °C ≤Ta ≤ +50 °C
● 6DR5ayb-0cdef-g*Ah-Z jjj
for a = 0, 1, 2 and f = 0, 2
-30 °C ≤Ta ≤ +80 °C -30 °C ≤Ta ≤ +60 °C
● 6DR5ayb-0cdef-g*Ah-Z M40
for a = 0, 1, 2 and f = 0, 2
-40 °C ≤Ta ≤ +80 °C -40 °C ≤Ta ≤ +60 °C
Technical data
12.5 Certificates and approvals
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 245
