5. Connect the wires of the cable ② to the connecting terminals ④ and to the SUB-D male
connector ① according to the following table:
Connecting
terminals
④ / ⑤
Assignment Assignment,
male
connector ①
Connecting
terminals
④ / ⑥
Assignment Assignment,
male
connector ①
2
3
4
5
GND
Vref
Vcc
Vpos
7
6
-
4
6
7
8
9
10
Not assigned
Discharge +
Discharge -
Supply +
Supply -
-
2
1
15
14
6. Connect the positioner 6DR5910 ③ with the 19" slide-in module ⑬ using the SUB-D male
connector ①.
7. Connect the wires of the cable ⑧ to the signal source ⑨ and the power source ⑪ as well
as the SUB-D female connector ⑦ according to the following table:
Assignment of female connector ⑦ for ⑨ Assignment of female connector ⑦ for ⑪
1
2
3
4
5
Signal source +
Signal source -
-
-
-
6
7
8
9
-
-
U
Aux
+
U
Aux
-
8. Connect the 19" slide-in module ⑬ with the control system ⑩ using the SUB-D female
connector ⑦.
F.2.3 Technical specifications of 19" slide-in module 4 to 20 mA
You can find the valid technical specifications for the positioner Technical data (Page 239). The
technical specifications valid for the 19" slide-in module 4 to 20 mA are set out below.
Rated conditions
Degree of protection
● Front
IP40 acc. to DIN EN 60529
● Back page
IP20 acc. to DIN EN 60529
Mounting position Any
Vibration resistance
● Harmonic oscillations (sine wave) according to
DIN EN 60082-2-6/05.96
3.5 mm (0.14"), 5 ... 8.4 Hz, 4 cycles/axle
10 m/s² (33 ft/s²), 8.4 ... 500 Hz, 4 cycles/axle
● Oscillations (sinusoidal) according to
DIN EN 60068-2-6/04.96
KWU DD 7080.9/93
KTA 3503 from 11.86
● Shock (half-sine) according to DIN EN 60068-2-27/02.2010
150 m/s² (492 ft/s²), 11 ms, 6 shocks/axle
Positioner with remote control electronics
F.2 19" slide-in module
SIPART PS2 with 4 to 20 mA/HART
316 Operating Instructions, 11/2019, A5E00074631-AE
