Siemens SIPART PS2 series User Manual

6DR5a*b-0cdef-g**h-Zjjj If enclosure
b =
If type of protection
c =
If order code
Z =
Enclosure version b =
0, 1, 2, 3, 5, 6
Type of protection c =
D, E, F, G, K
Connection thread d =
● G, N, M, P, R, S
0, 1, 2, 3
● G, N, M, P, Q
5, 6
Limit monitor e =
0, 1, 2, 3, 9
Option modules f =
0, 1, 2, 3
Customer-specific design g =
0, 3, 7
Pneumatic accessories h =
0, 1, 2, 3, 4, 9R**
Order code Z = jjj
A**, C**, D53…D57, F**, K50, L1A,
M40, P01…P02, R**, S**, Y**
12.5.2 Basic unit and optional modules
Type of protection 6DR5ayb-*cdef-g*Ah-Zjjj Ex marking
ATEX 205947X
IECEx TUN 17.0023X
Ex marking
FM 17US0053X
CSA 18CA70166848X
For c = D,
● a = 0, 2, 5, 6 and b = 1, 2, 3
● a = 1 and b = 3
II 2 D Ex tb IIIC T100°C Db
II 3 G Ex ec IIC T6/T4 Gc
Zn 21 AEx tb IIIC T100°C Db
Zn 21 Ex tb IIIC T100°C Db
DIP Cl II, III Div 1 Gp E-G
Cl I Zn 2 AEx nA IIC Gc
Cl I Zn 2 Ex nA IIC Gc
NI Cl I Div 2 Gp A-D
For c = E,
● a = 0, 2, 5, 6 and b = 0
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
Cl I Zn 1 AEx ib IIC Gb
Cl I Zn 1 Ex ib IIC Gb
IS Cl I Div 1 Gp A-D
For c = E,
● a = 0, 2, 5, 6 and b = 1, 2, 3
● a = 1 and b = 3
II 2 G Ex ia IIC T6/T4 Gb
II 3 G Ex ic IIC T6/T4 Gc
II 2 D Ex ia IIIC T130°C Db
Cl I Zn 1 AEx ib IIC Gb
Cl I Zn 1 Ex ib IIC Gb
Zn 21 AEx ib IIIC, T130°C Db
Zn 21 Ex ib IIIC, T130°C Db
IS Cl I, II, III Div 1 Gp A-G
Technical data
12.5 Certificates and approvals
SIPART PS2 with 4 to 20 mA/HART
244 Operating Instructions, 11/2019, A5E00074631-AE
