SWT 3000 Equipment Manual Chapter 3: Service program PowerSys
© SIEMENS AG 2008 Edition p3_3_2x 08/09 Page - 7
Connection
Figure 6: Configuration of the serial interface from the Service PC
The communication to the device can be carried out either via the serial interface from the PC or
via a TCP/IP connection. The configuration is done after operating the button.
Figure 7: Configuration for the TCP/IP connection
The timeout for the serial interface
of the service PC is adjustable
from 4 – 60 sec.
In case of RM connection the
timeout of the RM channel has to
be adjusted in the <PowerLink
Configuration RM> form.
The timeout for the LAN interface
of the service PC is adjustable
from 4 – 60 sec.
