SWT 3000 Equipment Manual CLE Module
© SIEMENS AG 2008 Edition p3_3_x 08/09 Page - 9
Connecting cable to the PLC unit ESB 2000i
The cable connection illustrated below is needed for connecting a remote SWT 3000 to the
ESB 2000i PLC system (CLE - NFD):
CLE NFD
c11
c13
a11
c11
a10
c10
c7
c9
a13
a1,c1,a31,c31
c3
c5
F6
F6
S6
a20
a1,c1,a31,c31
F6 Protection signals
S6 Control wire to the PLC unit in alternate multi-purpose mode
NFD Interface module of the PLC unit
Figure 7: Cable connection from the CLE to the PLC unit ESB 2000i
Connection of an external SWT 3000 to the PowerLink 50/100
The connection of the CLE module from an external SWT 3000 to the SUB-D female connector of
the VFx modules is shown in the figures below. In this case the VFx ports 3 resp. 4 must be used.
VFx port 3
CLE
CFS-2
P12V
S6IN_A
S6OUT
GND12
S6IN_B
S6OUT_GND
F6OUT_A
F6IN_B
F6IN_A
F6OUT_B
a18
c13
c11
a20
c5
c3
c9
c7
4-wire input A
X1
VFx
SWT 3000
PowerLink
4-wire input B
4-wire output A
4-wire output B
SUB-D connector
Connector panel
Port 3
12
31
10
29
11
30
Figure 8: Connecting an external SWT 3000 to the port 3 of the VFx modules
