SWT 3000 Equipment Manual Installation and Commissioning
Jumper settings of the FOB
Table 31: Selection of the digital interface
Jumper
Interface X2 X3 X6 X7 X14 X15 X16 X18 X19
X.21
2Mbit/s
Pin 1-2
11-12
1-2
11-12
2-3 1-2 2-3 2-3 2-3 1-2
X.21
64kBit/s
Pin 1-2
11-12
1-2
11-12
2-3 2-3 2-3 2-3 2-3 1-2
G703.1 Pin 3-4
13-14
3-4
13-14
1-2 2-3 2-3 2-3 2-3 2-3
G703.6
sym.
Pin 5-6
15-16
5-6
15-16
1-2 1-2 2-3 2-3 2-3 1-2 2-3
G703.6
coax
Pin 7-8
15-16
7-8
15-16
1-2 1-2 1-2 1-2 1-2 2-3 1-2
Table 32: Setting options long haul or short haul
Operation mode Jumper X17
Long haul 1-2
Short haul 2-3
Table 33: Setting options normal mode / isolation test
Operation mode Jumper X8 Jumper X9
Normal mode 1-2 1-2
Isolation test 2-3 2-3
Table 34: Selection of DTE or DCE mode
Operation mode Jumper X5
FOB as DTE 2-3
FOB as DCE 1-2
© SIEMENS AG 2008 Edition p3_3_2x 08/09 Page - 27
