112 MS 201, MS 201 C, MS 201 T, MS 201 TC
12.9.3 Tank Vent (MS 201 T)
– Remove the filter base, b 12.3.1
: Use a screwdriver to pry out the
tank vent (1) at the recess
(arrow).
– Pull the tank vent (1) out of the
hose.
Always install a new tank vent.
– Position the new tank vent (1) so
that it points toward the seat.
: Push the tank vent (1) into the
vent hose (2) and into its seat
(arrow) as far as stop.
– Reassemble all other parts in the
reverse sequence.
7013RA270 TG
1
7013RA271 TG
1
2
12.10 Fuel Intake
12.10.1 Pickup Body
Impurities gradually clog the fine
pores of the filter. This means that
fuel intake is insufficient.
In the event of problems with the
fuel supply system, always check
the fuel tank and the pickup body
first.
– Troubleshooting, b 3.6 or
b 3.7
Clean the fuel tank if necessary.
– Open the tank cap and drain the
tank.
– Pour a small amount of clean fuel
into the tank. Close the tank and
shake the saw vigorously.
– Open the tank again and drain it.
– Dispose of fuel properly in
accordance with environmental
requirements, b 1
– Open the tank cap.
: Use hook (2) 5910 893 8800 to
remove the pickup body (1) from
the fuel tank.
7013RA182 TG
2
1
Do not overstretch the fuel suction
hose.
– Check the pickup body (1) and
replace if necessary
– Reassemble in the reverse
sequence.
12.10.2 Fuel Suction Hose
The removal and installation
procedure is the same on the
MS 201 and MS 201 T.
– Remove the pickup body,
b 12.10.1
– Remove the handle housing,
MS 201 b 10.4, MS 201 T
b 10.5
: Pry out elbow connector (1) with
fuel suction hose (2) at the lug
(arrow).
7013RA400 TG
2
1
