Stihl Ms 201 User Manual

5MS 201, MS 201 C, MS 201 T, MS 201 TC
2. Specifications
2.1 Engine
MS 201 MS 201 T
Displacement: 35.2 cm
3
35.2 cm
3
Bore: 40.0 mm 40.0 mm
Stroke: 28.0 mm 28.0 mm
Engine power to ISO 7293: 1.8 kW (2.4 bhp)
at 9,500 rpm
1.8 kW (2.4 bhp)
at 9,500 rpm
Cut-off speed
with bar and chain: 14000 rpm 14000 rpm
Idle speed: 3,000 rpm 3,000 rpm
Clutch: Centrifugal clutch without
linings
Centrifugal clutch without
linings
Clutch engages at: 3,700 rpm 3,700 rpm
Crankcase leakage test
at gauge pressure: 0.5 bar
under vacuum: 0.5 bar
2.2 Fuel System
Carburetor leakage test at gauge pressure: 0.8 bar 0.8 bar
Operation of tank vent at gauge pressure: 0.5 bar 0.5 bar
Fuel: as specified in instruction
manual
as specified in instruction
manual
2.3 Ignition System
Air gap between the ignition module and
flywheel: 0.30 (+ 0.05/- 0.10) mm 0.30 (+ 0.05/- 0.10) mm
Spark plug (resistor type): NGK CMR 6 H NGK CMR 6 H
Electrode gap: 0.5 mm 0.5 mm
2.4 Chain Lubrication
Speed-controlled oil pump with reciprocating piston and manual flow control or Ematic
Settings for oil delivery rate:
min.:
max.:
Ematic:
3.5 (+/1.0) cm
3
/min
at 7,000 rpm
9.5 (+/2.0) cm
3
/min
at 10,000 rpm
6.5 (+/1.5) cm
3
/min
at 10,000 rpm
3.5 (+/1.0) cm
3
/min
at 7,000 rpm
9.5 (+/2.0) cm
3
/min
at 10,000 rpm
6.5 (+/1.5) cm
3
/min
at 10,000 rpm
