120 MS 201, MS 201 C, MS 201 T, MS 201 TC
13. Special Servicing Tools
New Special Tools
Existing Special Tools
No. Part Name Part No. Application Rem.
1 Installing sleeve 1145 893 4600 Protecting the oil seal
(clutch side/ignition side)
2 Locking strip 1145 893 5900 Blocking the crankshaft
3 Flange – intake side 5910 850 4203 Leakage test
No. Part Name Part No. Application Rem.
1 Carburetor and engine tester 0000 850 1300 Testing engine and carburetor for leaks
- Nipple 0000 855 9200 Testing carburetor for leaks
- Hose for leakage test 1110 141 8600 Testing carburetor for leaks
2 Sealing plate 0000 855 8106 Testing engine for leaks
3 Installing tool 0000 890 2201 Installing rope guide bushing
4 Combination wrench 0000 890 3402 Spark Plug 1)
5 Clamping strap 0000 893 2600 Compressing the piston rings
6 Screwdriver bit, T 20 x 125 0812 542 2041 Removing and installing spline socket
screws with electric or pneumatic
screwdrivers; tightening down screws
with torque wrench
7 Screwdriver bit, T 27 x 125 0812 542 2104 Removing and installing spline socket
screws with electric or pneumatic
screwdrivers; tightening down screws
with torque wrench
8 Wooden assembly block 1108 893 4800 Supporting the piston
9 Setting gauge 1111 890 6400 Adjusting air gap between the ignition
module and flywheel
10 Assembly drift 1114 893 4700 Removing and installing piston pin
11 Assembly tube 1117 890 0900 Attaching springs
12 Press sleeve 1120 893 2400 Installing oil seal (clutch side / ignition
side)
13 Service tool AS (set) 5910 007 2205 Separating two halves of crankcase
14 Clamping strap for assembly
stand
5910 850 1650 Clamping machine to assembly stand
15 Ignition system tester, ZAT 4 5910 850 4503 Testing ignition system
16 Ignition system tester, ZAT 3 5910 850 4520 Testing ignition system
