Maintenance and Lubrication: 0B-28
Specifications
Tightening Torque Specifications
BA02J20207001
NOTE
The specified tightening torque is described in the following.
“Chassis Bolt and Nut Inspection” (Page 0B-26)
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List” in Section 0C
(Page 0C-8).
Special Tools and Equipment
Recommended Service Material
BA02J20208001
Fastening part
Tightening torque
Note
N⋅mkgf-mlbf-ft
Air cleaner heat guard mounting screw 1 0.1 0.7 )(Page 0B-5)
Engine oil level check bolt 5.5 0.55 4.0 )(Page 0B-6)
Oil drain plug 12 1.2 8.5 )(Page 0B-7)
Magneto cover bolt 11 1.1 8.0 )(Page 0B-7)
Oil filler cap bolt 11 1.1 8.0 )(Page 0B-8)
Oil strainer cap 21 2.1 15.0 )(Page 0B-8)
Engine coolant drain plug 11 1.1 8.0 )(Page 0B-10)
Radiator air bleeder bolt 6 0.6 4.5 )(Page 0B-10)
Cable adjuster lock-nut
2.1 0.21 1.5
)(Page 0B-11) /
)(Page 0B-12) /
)(Page 0B-13)
Exhaust pipe bolt and nut 23 2.3 16.5 )(Page 0B-18)
Muffler mounting bolt 23 2.3 16.5 )(Page 0B-18)
Muffler connector clamp bolt 19 1.9 13.5 )(Page 0B-18)
Exhaust pipe cover bolt 11 1.1 8.0 )(Page 0B-18)
Muffler tail cover screw
10 1.0 7.0
)(Page 0B-18) /
)(Page 0B-19)
Spark arrester mounting bolt 5.5 0.55 4.0 )(Page 0B-19)
Rear axle nut 100 10.0 72.5 )(Page 0B-21)
Rear brake master cylinder rod lock-nut 6 0.6 4.5 )(Page 0B-23)
Front fork air bleeder valve 1.3 0.13 1.0 )(Page 0B-24)
Spoke nipple 6 0.6 4.5 )(Page 0B-25)
Wheel rim lock (Front) 14 1.4 10.0 )(Page 0B-25)
Wheel rim lock (Rear) 14 1.4 10.0 )(Page 0B-25)
Material SUZUKI recommended product or Specification Note
Brake fluid DOT 4 — )(Page 0B-22)
Grease SUZUKI SUPER GREASE “A” or
equivalent
P/No.: 99000–25010 )(Page 0B-12)
Sealant SUZUKI BOND No.1215 or
equivalent
P/No.: 99000–31110 )(Page 0B-19)
To Next Page
