1. Key
‘3
2. Crankshaft pulley
3.
Pulley bolt
Fig. 3-6-52 Installing crankshaft pulley
2) Install alternator assembly.
Tighten alternator ass’y securing bolts
(3pcs)
only to the extent to allow alternator to be
moved by hand. Don’t torque them tight.
NOTE:
Adjust water pump belt tension to specification
upon completion of installing engine ass’y to
body and then cooling fan and water pump
pulley. Make sure to refer to p. 1-5 of this
manual for adjusting procedure.
Distributor Case
1) Install distributor case O-ring to cylinder
head.
2) Install distributor case.
3) Tighten bolts to specified torque.
Tightening torque
N.m
kg-m lb-ft
for
case
bolts
8
-
12
0.8
-
1.2
6.0
-8.5
Fig. 3-6-53
Fuel Pump
Install fuel pump rod, gasket and fuel pump to
cylinder head.
Apply engine oil to rod
@
before installation.
Use new gasket.
Fig. 3-6-54 Fuel pump rod installation
case with about
3Occ
(1.02/1.05
US/Imp
3-51
