8) Inspect Magnetic Switch
Hold in coil open circuit test
Push in plunger and release it. The plunger
Check for continuity across magnetic switch ‘S’
should return quickly to its original position.
terminal and coil case. If no continuity exists,
Replace if necessary.
the coil is open and should be replaced.
Fig. 925
Pull-in coil open circuit test
Check for continuity across magnetic switch
‘s’ terminal and ‘M’ terminal. If no continuity
exists, the coil is open and should be replaced.
Fig. 926
Fig. 927
REASSEMBLY
Reverse disassembly procedure, using care on
following points.
l When installing pinion drive lever, refer to
Fig. g-2 for its installation direction.
0. When installing brush holder, be careful of
brush position.
2
3
1. Brush holder
2. Yoke
3. Brush positions
Fig. 9-27- 1
