9-8. CLUTCH SWITCH
Install clutch switch in such a way that clearance
between thread end of clutch switch and clutch
pedal (distance 3 in Fig.
9-32)‘satisfies
following
specification when clutch pedal is depressed
fully.
Tighten clutch switch lock nut to specified
torque.
Clutch switch thread
end-to-clutch pedal
l.O-1.5mm
clearance
(0.04
-
0.06
in
)
9-
12
233
235
