2) For right-hand side steering vehicle.
Air cleaner outlet
hose
Aircleaner
Radiator outlet
Air cleaner outlet hose
Clutch cable
Cla&p
Viewed from arrow “A”
40 - 60 N.m
4.0 - 6.0 kg-m
I
Viewed from arrow “6”
Radiator
Fig. 11-23
Warmair hose
Viewed from arrow “C”
11-6. RECOMMENDED TORQUE SPECIFICATION
Be sure to torque each nut or bolt, if loosened, to specification given below.
If specified tightening torque for particular bolt or nut is not included here, refer to p. O-12 of this manual.
Fastening Parts
Tightening torque
, N.m
kg-m
lb-ft
1. Flywheel
bolts 57 - 65
5.7 - 6.5 41.5 - 47.0
2. Clutch cover bolts
18-28
1 .B - 2.6 13.5 - 20.0
3. Clutch release arm
bolt and nut lo- 16
1 .O - 1.6 7.5 - 11.5
.
11-10
