11. Remove oil seal and outer race of inner
bearing or outer bearing from wheel hub.
Fig. 17-1-18
Steering Knuckle
1. Remove front wheel hub, referring to steps 1
to 10 of foregoing front wheel hub and
bearing removal.
2. Loosen bolts securing kingpins (upper &
lower). At this point, king pins mustn’t be
removed.
Fig. 17-1-19
3. Remove disc dust cover, caliper holder and
wheel spindle.
Fig. 17-1-20
4. Remove tie rod end castle nut and disconnect
tie rod end from steering knuckle with
special tool @.
Fig. 17-1-21 Special tool @ (Tie Rod End
Remover 09913-65210)
5. Remove joint seal bolts. Then remove oil seal
cover, pad, oil seal and retainer from knuckle.
Fig. 17-1-22
17-8
